3522777H Holset H1C fabriksny originalturbo ( Bytesturbo )

  • 10 000 kr

3522777H Holset H1C fabriksny originalturbo. ( Beställningsvara 1-2 dagars levtid ) Fabriksny originalturbo som tas in i vårat bytessystem.Monteringssats i

I lager.
Article Number: 3522777-BT
Share

3522777H Holset H1C fabriksny originalturbo. ( Beställningsvara 1-2 dagars levtid )

Fabriksny originalturbo som tas in i vårat bytessystem.

Monteringssats ingår vid köp utav denna turbo online.

Turbonummer / ersättningsnummer / Originalnummer / Turbofakta :

Part Number3522777
Previous Version 3522778
OE number3802289, J919121,  J907029, J919117, J907028, J919115, J919113, J907026, 3528742, 3535414,  3535419, 3535417, 3535418, 3535416, 3538188, 3535415, 3535420, 3535454,   3530714, 3535421, 3528741, 3530772
DescriptionTractor Komatsu Industrial CDC
CHRA3523317 (3545713)
Turbo ModelH1C, H1C-8243AF/E18DA11
Engine6BTA, 6T-590, 6BT-590, 6BTA-590
Manufacturer Part Number3528741
Displacement 5.9L, 59080 ccm
FuelDiesel
Engine ManufacturerCummins,  J I Case
Angle α (compressor housing)209/213/304/310/320/323/327/337/340/345/360°
Angle β (turbine housing)5/20/130/165/169/180/360°
Bearing Housing3530591 (3530592)(1152301450
Turbine Wheel3519336 (3595832)(Ind. 70.0 mm, Exd. 59.9 mm, 12 Blades) (1152301435
Comp. Wheel 3521711 (3599639)(Ind. 50. mm, Exd. 83. mm, 8+8 Blades) (1152301400)
Back plate3522801
Heat shield Number3519302 (1152301340)
Repair Kit3545652 (4027309)(3802148)(1152301750)
Turbine Housing3519409
Compressor Cover3522390
Gasket (turbine inlet)409039-0000 (409039-0001, 210019, 312617, 2405022, 7C7431)(1900000006) (Inox Steel) $13.52
Gasket oil inlet210023  (210023-0000, 147837, 210021, 215234, 55739, 3709737, 3500681, 3519762,  409266-0001, 409036-0000, 409026-0001, 52231586500)(1900000037) $4.48
ManufacturerHOLSET

Interchangeable with 166592


Applications


1986-03 Cummins Agricultural Tractor with 6T-590, 6BT-590, 6BTA-590

JI Case Agricultural Tractor with 6T-590, 6BT-590, 6BTA-590 Engine

1986-03 Komatsu Industrial Tractor with 6BTA
