49131-02000 Mitsubishi : TD03-07G Marinturbo Nanni ( Storsäljare )

  • 14 999 kr
  • 13 499 kr

49131-02000 Mitsubishi : TD03-07G Marinturbo Nanni ( Storsäljare )Vanligt fel att denna turbon rostar igen totallt på avgassidan.Turbonummer / Originalnummer /

I lager.
Artikelnummer: 1776
Dela

49131-02000 Mitsubishi : TD03-07G Marinturbo Nanni ( Storsäljare )


Vanligt fel att denna turbon rostar igen totallt på avgassidan.

Turbonummer / Originalnummer / Produktfakta :

Part Number49131-02000
Previous Part Number4913102000 , 49131-02020 , 49131-02010
OE number06103007, 16483-17012, 16483-17010, 16483-17015, 1648317010, 1648317015, 16483-17013, 960606092
DescriptionTractor, Marine
CHRA49131-08010 (49131-08000, 49131-08041) $289.00 NEW IN STOCK, MADE IN USA
Turbo ModelTD03-07G, TD03-07B, TD03-07G-4.8
Engine F2503, F2503-TE-C-C
Engine ManufacturerKubota Mitsubishi
Capacity2.5L, 2499 ccm
Power 63 Kw
FuelDiesel
Bearing Housing49131-25400 (Oil Cooled)
Turbine Wheel49131-30100 (Ind. 40.18 mm, Exd. 35.07 mm, Trm 6.45, 12 Blades)(1100016096)
Comp. Wheel49131-43200 (Ind. 32.64 mm, Exd. 44.01 mm, Trm 3.73, 6+6 Blades)(1200016211)
Back plate(Superback)(1401402300, 1800016016)
Heat shield, Shroud$12.72 NEW IN STOCK
Repair Kit49131-10400 $79.60 NEW IN STOCK
Turbine Housing49131-55200
Actuator49131-18300
settings Waste gate (pressure) 1.03-1.07 bar
settings Waste gate (lift shaft)0.38 mm
GasketOil Outlet$3.00
Gasket Kit$13.00
ManufacturerMitsubishi


Applications


 Kubota Marine 5.250 TDI  Engine  Nanni 5.250

 Kubota Tractor Engine  F2503-TE
